General:
Cockpit deck, all welded aluminum, self-draining
Side storage trays in cockpit with boarding steps
Bowrails and cockpit handrails 1” aliminum pipe, welded
Cabin top handrails, ¾” aluminum pipe, welded
Radar arch, 1”aluminum pipe, welded, with antenna and GPS mounts
Anchor roller, ¼” plate, welded with 3” roller
Anchor rode locker, with drains and access hatch
Swimstep, 24” welded, with welded transom grab handles
Cleats, seven 8” cast aluminum, welded
Fairlead chocks ,cast aluminum, welded
Engine hatch, hinged, weather tight
Fuel tank, one, 150 gallon, bolt in, w/gauge sender
Fuel tank access, bolt down plate on deck to access entire fuel tank
Bilge pumps, 2-Jabsco 1500 GPH w/automatic float and panel switches
Trim-tab system, Boat Leveler 9" x 18"
Running lights, Aqua Signal series 20
Horn, AFI 10029 XLP electric dual trumpet
Doors and windows, All heavy duty aluminum frame Diamond /Seaglaze
With ¼” tempered glass
Extensive acoustic insulation throughout
1-Zinc anode on hull
Large comfortable finished forecabin
Quiet, comfortable pilothouse style main cabin
All interior stick built, with structural aluminum welded in place
Electrical System DC:
Batteries, 2-Exide NG31 D 12 Volt Deep cycle (105 amp hours each)
Battery switch, Blue sea systems heavy duty
Main DC circuit breaker, Blue Sea Systems 185 series
Electrical panel, Blue Sea Systems 8023 with 8 toggle circuit breakers
Dash switch panel, 10 Contura rocker switch with push-to-reset circuit breakers
12V DC outlet, one at dash
Wiring, all fine stranded marine grade duplex tinned copper
Connectors and fittings, all “Ancor” marine grade
Electrical system AC:
Shore power system, 30 Amp,
Power inlet, Marinco 303 ELB
Shore power cord, 50' Marinco
Electrical panel AC, Blue Sea 8027 with main breaker, polarity indicator
and 5 toggle breakers for branch circuits
Electrical outlets, 2- duplex, one at galley and one at dinette
Battery charger, Statpower Truecharge 40 amp
All fine stranded marine grade triplex tinned copper wire
All Ancor marine grade connectors and fittings
All wiring is fine stranded marine grade, triplex, tinned copper
All electrical connectors are Ancor brand
Fresh Water System:
Fresh water tank, 40 gallon, heavy duty rotomolded plastic
Fresh water pump, Jabsco Sensor Max 3.6 gpm variable speed automatic
Galley sink, Polar stainless, single 9”deep
Galley faucet, Skandvic 10488 single lever
Water heater, Isotherm 6 gallon heat exchanger/ 120 volt
Shower, Heatercraft 303SB stow away
Shower drain system, Attwood 4143-4 automatic
Washdown faucet on deck (fresh water)
All fine stranded marine grade tinned copper wire
Head system:
Painted aluminum head compartment with teak door
Groco model HF manual marine toilet
Waterproof self retracting toilet paper holder
Stainless towel bar
Holding tank, 10 gallon heavy duty rotomold plastic
All fittings and penetrations on top of tank
Waste discharge pump, Whale Guzzler manual diaphragm
Deck discharge for dockside vacuum system
Cabin / Interior:
Forecabin 6’3”length includes:
Berth, V-berth with upholstered 4"cushions
Storage shelf forward with carpet liner and teak trim
Portlites, 2-Lewmar Ocean series, opening with screens
Skylight hatch, Bomar 1029-10 with screen
Panel headliner with acoustic foam insulation
Cabin light, red / white
Access to anchor locker
Marine carpet hull liner
Cabin / Interior:
Main cabin, pilothouse style, 7’3” length;
Helmstation starboard side with polished aluminum dash
Helmseat, Bentleys Rivermaster with folding armrests on Garelick slide
Storage cabinet, under helmseat with one shelf and door
Storage, open under helm floor
Bench seat or 41”galley cabinet starboard side
Dinette cabinet portside includes;
Bench seats, face to face
Table, 30”x 42”with teak sea rail
Dinette converts to berth 42”x 77”
Storage under dinette seats with top access
Windows, forward, 3 Diamond Seaglaze D5 fixed, with windshield wipers
Windows, side, 2 each side, sliding, Diamond Seaglaze 106S
Windows, rear, 2, Diamond Seaglaze D5 fixed
Entry door, heavy duty aluminum, Diamond Seaglaze, with drop-slide window
And stainless Trio-Ving deadbolt lockset
Options and extras in addition to standard equipment
Extend cabin 6” to make 6’5” dinette
Increase cabin headroom 3”
Head, enclosed, painted, compartment portside fwd with
manual toilet, 10 gallon holding tank and manual pump-out
Discharge pump, electric
Y Valve overboard add
Water system,
20 gallon Deluxe fresh water system with 3.6 gpm
automatic pump, 6 gal. heat exchanger / 110 V
water heater, stow-away shower in head, and single
stainless galley sink with faucet
Upgrade to 40 gallon fresh water capacity
Deck faucet
Battery charger, Statpower Truecharge 40A 12v
Davit, standard Seawolf roof mounted heavy duty
with Saf-T-Puller 300 lb 12 volt pot puller
Decklight, halogen 3”x 5”
Drawer, (1) in gally under stove
Filet table, removeable, large,on engine box
Fuel, auxiliary tank for kicker (9gal)
Fuel, main tank upgrade to 149 gals.
Furnace, diesel, Wallas 40 D
Helm, auxilliary, with hydraulic steering and main by-pass valves
Refrigerator, Nova Kool 2.4 cu. Ft.
Rod holders 12 total (rocket launcher)
Shorepower, 30 amp, AC panel with 30 amp main,
3 15 amp breakers, 2 duplex oulets, 50’ cord
Stereo, Jensen marine CD with 4 Poly-Planar waterproof speakers
Storage, holds, aft deck full cockpit length each side
approx. 24” wide x 12” deep with macerator pumpout
Storage, hold, below aft deck on center, 30” long x 4’ wide aprox.
with Rule bilge pump out
Storage, deckbox with cushion, large
Stove, Wallas 125 U diesel cook/heat stove
Washdown, Raw water Parmax
Windlass, Simpson Lawrance Horizon 900G with foot switches
and reversing solonoid Yamaha T8 hi thrust electric start power tilt remote control
with hydraulic steering ram
Salt water faucet on houseback
Hot fresh water faucet on houseback
Increase swimstep to 28”
Add separate group 24 start battery with battery combiner
Electric winch on cabin roof to pull dingy onto aft deck
Scotty rod holders (6) on cockpit railss
Downrigger mounts (2) on cockpit rails
Scotty rod holders (2) on bowrails
Decklite under aft console
Hanger rods in head for clothes drying
Anchor, 22 lb Bruce with 50’ 5/16” chain and 600’ 3 strand nylon rode
Access door under dinette seats
Auxilliary raw water flush for head
Defog fans
Electronics package:
Radar: Furuno 1833 C
Heading sensor: Furuno PG 1000
Sounder: Furuno BBFF 1
Transducer: Furuno CA 50/200 1T on Seawolf welded bracket
GPS: Furuno BB GPS
VHF: ICOM M 402
Antenna: Shakespeare 5225 XT
